casa / prodotti / Optoelettronica / Illuminazione a LED - Bianco / GW JDSMS1.CC-FRFT-5O8Q-L1N2
codice articolo del costruttore | GW JDSMS1.CC-FRFT-5O8Q-L1N2 |
---|---|
Numero di parte futuro | FT-GW JDSMS1.CC-FRFT-5O8Q-L1N2 |
SPQ / MOQ | Contattaci |
Materiale di imballaggio | Reel/Tray/Tube/Others |
serie | DURIS® E 5 |
GW JDSMS1.CC-FRFT-5O8Q-L1N2 Stato (ciclo di vita) | Disponibile |
Stato parte | Active |
Colore | White, Warm |
CCT (K) | 3500K |
Flux @ 85 ° C, Current - Test | - |
Flux @ 25 ° C, Current - Test | 43 lm (38 lm ~ 48 lm) |
Corrente - Test | 120mA |
Voltage - Forward (Vf) (Typ) | 3.15V |
Lumens / Watt @ Current - Test | 114 lm/W |
CRI (indice di resa cromatica) | 90 |
Corrente - max | 180mA |
Angolo di visione | 120° |
Tipo di montaggio | Surface Mount |
Pacchetto / caso | 4-SMD, Flat Lead Exposed Pad |
Pacchetto dispositivo fornitore | 5630 |
Dimensione / Dimensione | 0.209" L x 0.118" W (5.30mm x 3.00mm) |
Altezza - Seduto (max) | 0.034" (0.87mm) |
Paese d'origine | USA/JAPAN/MALAYSIA/MEXICO/CN |
GW JDSMS1.CC-FRFT-5O8Q-L1N2 Peso | Contattaci |
Numero parte di ricambio | GW JDSMS1.CC-FRFT-5O8Q-L1N2-FT |
